Starter for Forklifts

Starters for Forklifts - A starter motors today is normally a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid installed on it. As soon as current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is situated on the driveshaft and meshes the pinion utilizing the starter ring gear which is seen on the engine flywheel.

The solenoid closes the high-current contacts for the starter motor, that begins to turn. After the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this way via the pinion to the flywheel ring gear. The pinion remains engaged, for example as the driver did not release the key when the engine starts or if there is a short and the solenoid remains engaged. This actually causes the pinion to spin separately of its driveshaft.

This above mentioned action stops the engine from driving the starter. This is an essential step since this particular kind of back drive would enable the starter to spin so fast that it will fly apart. Unless modifications were made, the sprag clutch arrangement will stop using the starter as a generator if it was employed in the hybrid scheme discussed earlier. Usually a standard starter motor is intended for intermittent use that would prevent it being utilized as a generator.

The electrical components are made so as to work for roughly 30 seconds to prevent overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical parts are intended to save weight and cost. This is the reason the majority of owner's handbooks for automobiles suggest the driver to stop for at least 10 seconds right after each and every ten or fifteen seconds of cranking the engine, if trying to start an engine which does not turn over right away.

In the early part of the 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was utilized. The Bendix system operates by placing the starter drive pinion on a helically cut driveshaft. As soon as the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, therefore engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.

During the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design which was made and launched during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism together with a set of flyweights in the body of the drive unit. This was an improvement in view of the fact that the standard Bendix drive used to be able to disengage from the ring once the engine fired, even if it did not stay functioning.

When the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement can be avoided before a successful engine start.
